| Improved W3D importer for 3d studio max now available [message #435775] |
Sat, 28 August 2010 23:58  |
|
|
Get it from
http://www.cncmods.net/files/w3dimport.zip
It can now import a lot more including wwskin (creating the wwskin "crossbones" object, linking the mesh to the object and linking the vertexes to the bones), materials (setting all the settings correctly) and w3d flags (collision etc etc). It does not import multiple materials assigned to a single mesh (it will import the first material and apply it to the whole mesh), objects set to "NULL (LOD)" in the w3d tools roll-out, the valpha checkbox and possibly a few other things.
Included in the zip file is:
w3dms.dlx New w3d maxscript extention plugin to allow maxscript access to various pieces of data specific to the W3D export plugin (w3d flags, materials etc)
w3dms.txt documentation of the maxscript functions supported by w3dms.dlx and by the W3D export plugin
w3d-importer.ms updated import script
max2w3d.dle updated w3d import plugin (there were a couple of options that existed in the gmax plugin but were disabled in the 3ds max plugin, I re-enabled them)
w3dms.vcxproj, w3dms.vcxproj.filters, dllmain.cpp, w3dms.sln Source code for w3dms.dlx (see COPYING for the license, basically it means that if you use my source code, you have to publish any changes you make and complete source code to any programs you use my code as part of)
To compile the plugin code you need visual C++ 2010 and you need the 3D studio max 8 SDK. If you have installed the 3D studio max 8 SDK in a folder other than the default, you will need to change the include and library paths in the project options to point to your SDK location.
The new importer and w3dms.dlx plugin are not compatible with gmax or any version of 3DS max other than version 8.
Please let me know if you make any improvements to the importer or w3dms.dlx plugin. Also let me know if you find any bugs, crashes, maxscript errors, things that wont properly import etc.
Jonathan Wilson aka Jonwil
Creator and Lead Coder of the Custom scripts.dll
Renegade Engine Guru
Creator and Lead Coder of TT.DLL
Official member of Tiberian Technologies
[Updated on: Sun, 29 August 2010 00:05] Report message to a moderator |
|
|
|
|
|
|
|
|
|
| Re: Improved W3D importer for 3d studio max now available [message #435787 is a reply to message #435775] |
Sun, 29 August 2010 07:26  |
|
|
Updated the script a bit more, I fixed an issue with material import and I made vertex painting work correctly (in that it imports the correct values)
To use the script, you need to put the w3d-importer.ms file into the scripts\startup folder. If you have a w3d-importer.mse file, delete it.
Put max2w3d.dle and w3dms.dlx into the plugins folder (replacing the existing max2w3d.dle file)
The other files are only relavent if you want to change the w3dms.dlx plugin.
Mr. Nice Guy, firstly make sure you have 3ds max service pack 3.
Secondly, make sure you have the w3d export plugin setup and working correctly.
Thirdly, make sure you have the max2w3d.dle file and w3dms.dlx from the w3dimport.zip file in the plugins folder.
The error where it highlights "wwSetSortLevel" and displays that error box indicates that you haven't put w3dms.dlx in the right place (meaning that 3DS Max cant find wwSetSortLevel which is inside w3dms.dlx)
Jonathan Wilson aka Jonwil
Creator and Lead Coder of the Custom scripts.dll
Renegade Engine Guru
Creator and Lead Coder of TT.DLL
Official member of Tiberian Technologies
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Re: Improved W3D importer for 3d studio max now available [message #435937 is a reply to message #435936] |
Wed, 01 September 2010 10:35 |
 |
Omar007
Messages: 1711
Registered: December 2007
Location: Amsterdam
Karma: 0
|
General (1 Star) |
|
|
| Jerad Gray wrote on Wed, 01 September 2010 18:47 |
| Omar007 wrote on Wed, 01 September 2010 08:19 |
*cough*download*cough*
|
Last time I checked there were no download links on the site, and all the torrents were dead, so unless you know of a legal site where they still distribute a free copy of 3dsmax8, I'm just out of luck.
|
I sadly cant give a link here if i'd upload it somewhere for you  (guess even though its not legally possible to get it, it's still warez?)
[Updated on: Wed, 01 September 2010 10:36] Report message to a moderator |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
